FrSky VANTAC RF007 TANDEM Flybarless

FrSky VANTAC RF007 TANDEM Flybarless

The FrSky VANTAC RF007 is a cutting-edge flybarless (FBL) helicopter flight controller, designed to leverage Rotorflight's latest 2.x flight control technology. With its built-in Twin 2.4GHz or Archer receiver, RF007 delivers a comprehensive range of features while providing intuitive configuration, seamless adjustments, and real-time tuning via the ETHOS radio interface.

Rotorflight Technology and Comprehensive Capabilities:

At the heart of the RF007 is an STM32F722 MCU processor, supported by a 3-axis gyro, 3-axis accelerometer, and a barometric sensor. Together, these components provide the precision and stability needed for pilots to rely on their models. Additionally, the flight controller supports flight data logging with a large 128MB Blackbox, giving users a wealth of data to optimize their model and troubleshoot issues.

Specifications:

● Flight Controller Firmware: Rotorflight 2.x

● Dimension: 43.5×31.2×13.7mm

● Weight: 25.2g

● Receiver Option:

- RF007 TANDEM: Built-In 2.4G&900M Dual-Band TD MX receiver

● Operating Voltage Range: 5-16V

● Operating Current (FC Only): 125mA@5V

● Voltage Measurement Range via AIN (External device): 0-80V

● RxUG Port: For Upgrading Internal RX Firmware (In case of OTA upgrade failure)

- Note: When powering this RxUG port, do not introduce additional power input from other ports to ensure the safe operation of the connected devices.

=====================================================================================

● MCU: STM32F722RET6

● Gyroscope (IMU): ICM-42688P

● Barometer: SPL06-001

● Blackbox Flash: 128MB

● Servo Ports: Servo 1, Servo 2, Servo 3, Tail

● ESC Ports: ESC (Throttle), RPM (Sensor), TLM (ESC Telemetry or other functions)

● Other Ports: AUX and SBUS Out/In

● Expansion Ports: Port A, C, and RxUG

Features:

● Runs Rotorflight 2.x Helicopter Control Software

● Built-In FrSky FBUS-Capable Receiver (TW or AP Protocol)

● Robust CNC Aluminum Case, Functional Heatsink for MCU

● STM32F722 Microcontroller for Power and Flexibility

● Precision Barometer, 3-Axis Gyroscope and 3-Axis Accelerometer

● 128MB Blackbox Function for Tuning/Troubleshooting

● 9 Primary Main Header Pins for Flexibility and Power Distribution

Includes:

1 x ROTORFLIGHT VANTAC RF007 Tandem dual band FBL Helicopter Flight Controller

1 x Connexion cable

1 x Programmation cable

1 x Manual
