Introducing the RCINPOWER GTS V2 1207 Motor, a compact and powerful micro motor designed for FPV enthusiasts.



Specification:



Configuration: 12N14P

Stator Diameter: 12mm

Stator Length: 7mm

Shaft Diameter: 1.5mm(2mm inside)

Idle Current(10V): 1.3A @ 5000/6000KV ;  1A @7500KV

Max. Con. Power (5S): 250W @5000KV ;  285W @6000KV

Max. Con. Power (180S): 250W @7500KV ;

Internal Resistance: 120mΩ @5000KV; 100mΩ @ 6000KV ; 110mΩ @ 7500KV

Max. Current(5s): 15A @ 5000KV

Max. Current(5s): 17A @ 6000KV

Max. Current(30s): 20A @ 7500KV

Motor Dimension(Dia*Len):21.3x27.6mm

Weight: 9.4g







Includes:



4 x RCINPOWER GTS V2 1207 5000KV MOTOR
